MIL-M-45122(Ora)
6. NOTES
6.1 Ordering data. - Procurement documents should specify the following:
a. Title, number and date of this specification.
b. Selection of applicable levels of packsging and packing.
6.2 Dimensions, cubage and weight of shipping containers.
6.2.1 Mount without equipment items.- The following inside dimensions,
page and gross weight are approximate for one unit packaged mount without
equipment items packed in a nailed wood box for Level A:
Inside dimensions - 16 inches long x 13+ inches wide x 15. inches deep
- 2.5 cubic feet
Cubage
Gross weight
- 95. pounds
6.2.2 Mount with equipment items.- Size and weight of packed shipping
container packed in a nailed wood box for Level A:
Inside dimensions - 19. inches long x 16
inches wide x 15. inches deep
3.6 cubic feet
Cubage
Gross weight - 108. pounds
6.3 Equipment items.- The following are the equipment items and are shipped
with the mount only when specified:
1
Box End Wrench
1
Cover M426
1
Extensions Assembly
1
Instrument Light M22
1
Instrument Light M35
6.4 Definitions.
6.4.1 Gage: A gage includes all precision standards and applicable
acessories which me calibrated to one basic size to provide an accurate
reference dimension.
6.4.2 Device, Special Testing (DST): Special. testing devices are designed
check function of an assembled unit.
6.4.3 Standard Measuring Equipment (SME): Standard measuring equipment
ME) includes the common hand type measuring devices which are usuaLly stocked
commercial supply houses for ready supply (shelf items), and which are normally
used by an inspector to perform dimensional inspection of Items under procurement.
This category also includes commercial testing equipment.
14.
