MIL-M-45122(Ord)
all be constructed as shown in Figure 1.
The dimension l
inches in Figure
shall apply.
5.3.2 .3.2.2 Instrument lights.- Each instrument light shall be packaged
specified in 5.3.1.5.2.2, except that the bag shall be omitted.
5.3.2.3.2.3 Extension assembly and box end wrench.- The extension
sembly and box end wrench shall be packaged as specified in 5.3.1.5.2.3,
cept that the bag shall be omitted.
5.3.2.3.2.4 Cover and wrapped items immobilized in a fiberboard box.-
e cover and wrapped items specified in 5.3.2.3.2.1, 5.3.2.3.2.2 and 5.3.2.3.2.3,
all be immobilized in a fiberboard box conforming to class 1, either type and
y style, except FTC, TS, OPF and FPF of Specification PPP-B-636. The fiber-
ard box shall be closed as specified in the appendix of Specification PPP-B-636.
5.4 Packing.
5.4.1 Level A.
5.4.1.1 Shipping container.- Each mount, bolted to a plywood base, shall
immobilized in a shipping container by nailing a hold-down cleat in each
corner of the container as shown in Figure 6. If the fiberboard box containing
the equipment items is to be packed in the shipping container, the width of the
mid-down cleats shall be such that the fiberboard box will fit between them.
The fiberboard box shall be immobilized in the container by nailing a hold-down
the container as shown in Figures 1 and 6. The shipping container shall
conform to either of the following Specifications:
PPP-B-601 - Style A or B (overseas type) - type II or III, class
2 Plywood
PPP-B-621 - Class 2 (overseas), style 2 or 4
5.4.2 Level B.- The requirements of 5.4.1.1 shall apply, except that the
container shall conform to the following:
PPP-B-601 - Any style under domestic type
PPP-B-621 - Class 1 (domestic) style 2 or 4
5.4.3 Level C.- The requirements of 5.4.1.1 shall apply, except that the
container shall conform to the following:
PPP-B-601 - Any style under domestic type
PPP-13-621 - Class 1 (domestic) any style except 1, 5 and 6.
12.
