MIL-M-45122(Ord)
conforming to Specification PPP-T-76 as specified in the appendix of Specifi-
cation PPP-B-636.
5.3.2 Level C.
5.3.2.1 Disassembling, cleaning and drying. - Disassembling, cleaning
and drying shall be as specified in 5.3.1.1, 5.3.1.2 and 5.3.1.3.
5.3.2.2 Preservative application. - The pin and mounting hardware shall
not be coated with a preservative. Preservative conforming to Specification
MIL-L-3150 (P-7 of Specification MIL-P-116) shall be applied on the unprotected
metal surfaces of the mount, socket and extension assembly. Preservative shalJ.
be applied by the brushing procedure specified in Specification MIL-P-116. Ex-
cess preservative shall be removed.
5.3.2.3 Unit packaging.
5.3.2.3.1 Mount without two instrument lights, box end wrench, cover and
extension assembly. - The mount without the equipment items shall be packaged
as specified herein, which is in conformance with Method I for the mount and
Method III for the mounting hardware, pin and socket, Specification MIL-P-116.
5.3.2.3.1.1 Mount. - The mount shall be packaged as specified in 5.3.1.5.1.1
to 5.3.1.5.1.5 inclusive, except that the bag specified in 5.3.1.5.1.2 shall be
omitted and the step bolts, nuts and washers specified in 5.3.1.5.1.5 shall not
be zinc or cadmium coated. The dimension 13. inches shall apply, in lieu of
the 1
inches referenced in Figure 1.
5.3.2.3.2 Mount with two instrument lights, box end wrench, cover and
extension assembly. - The mount with equipment items shall be packaged as
specified herein, which conforms to the methods listed below of Specification
MIL-P-116:
Item
Packaging Method
Telescope Mount
I
Socket
I
Hardware and pin (secured to socket)
III
Each instrument Light
III
Box end wrench (secured to extension assembly)
III
Cover
III
5.3.2.3.2.1 Mount, socket, hardware and pin. - The mount, socket, hardware
and pin shall be packaged as specified in 5.3.2.3.1.1, except that the wrapped
socket, hardware and pin shall not be secured to the mount, and a plywood base
11.
.
