MIL-S-17000/5A(SH)
2 May 1983
SUPERSEDING
MIL-S-17000/5(SH)
30 April 1980
MILITARY SPECIFICATION SHEET
SWITCHING EQUIPMENT, COMBAT SYSTEM, COMMAND AND CONTROL,
FIRE CONTROL AND INTERIOR COMMUNICATION SWITCHBOARD,
SURFACE SHIP, DECK-MOUNTED, TWO SEPARATE SECTIONS
(TERMINAL BOARD AND PLUG CONNECTED),
TYPE VI
This specification sheet is approved for use by the Naval Sea Systems
Command, Department of the Navy, and is available for use by all
Departments and Agencies of the Department of Defense.
The complete requirements for acquiring the switchboard described herein shall
consist of this document and the latest issue of MIL-S-17000.
REQUIREMENTS :
Switchboard section arrangement: Each switchboard front and rear section
shall be arranged as shown on figure 1. The front section shall provide
space for 36 panel-mounted assemblies. The back section shall contain six
modules.
Size:
Size of the switchboard sections shall be as shown on figure 1.
Mounting: Switchboard enclosure shall be provided with mounting bolt
clearance holes as shown on figure 1.
Preparing activity:
Navy - SH
(Project 1290-N381)
denotes changes.
FSC 1290
page 1/2 of 6
